Gooseneck 20' Flat +5' dove tail Big Tex 22GN for sale in Florida
ad ref. HT701644B

Big Tex 22GN Tandem Dual Gooseneck

22GN+20BK+ 5

Experience the difference with Big Tex, the best-selling brand of Professional Grade, Tandem Dual Trailers in the United States. Our 22GN model comes standard with host of features including our Low Profile design and HD Adjustable Suspension.

Advantages Of A Low Profile Design:

* Pierced Integrated Frame: Adds Strength and Longevity

* Low Center of Gravity: Provides Improved Handling During Tow

* Shallower Load Angle: Safer and Easier to Load

* Lower Deck Height (34''): Allows Taller Stacking of Loads

Heavy Duty Adjustable Suspension:

* Heavy duty mechanical design reduces road shock to cargo

* Improves integrity, reliability, and durability

* Extended life for equalizer bushings, less wear, and lower maintenance time and cost

* Adjustable to ensure proper tire tracking

Structural Details:

* 12'' I-Beam Frame & Neck

* 3'' Channel Crossmembers-Plasma Pierced Through Frame

* Torque Tube Standard on 28' (Flat Deck) & Longer

* 2 Side Bed Steps & Handles

* 1-1/4'' Pipe Chain Spool Between Stake Pockets

* 3/8'' Heavy Duty Rub Rail w/ Stake Pockets on 24'' Centers

* 3 Year Structural Warranty

* 5' Self Cleaning Dovetail w/ Variety of Ramp Options

Where the Rubber Meets the Road:

* Premium Dexter Oil Bath 10,000# Axles

* ST 235/80 R-16 Load Range E Dual Radial Tires

* Forward Self Adjusting Brakes

* Complete Break-A-Way System w/Battery & Charger

* Mudflaps

More Standard Features:

* Lockable Toolbox Between GN Uprights

* 30k Square Crank-Style Adjustable Coupler

* Dual 12k Drop-Leg Jacks w/ Greasable Handle (Bolted on for easy replacement)

* Sealed Modular Wiring Harness

* All Grommet Mount Sealed LED Lighting and Reflective Conspicuity Tape

* Spare Tire Mount

* 2'' Treated Pine Or Douglas Fir Floor (#2 or Better)

* 3/8'' Grd.70 Safety Chains w/Safety Latch Hook (2 each)

* Bead Blasted & Acid Etched Prep

* Automotive Grade Highly Decorative and Protective Finish

Optional Ad-Ons (Additional Cost)

* Electric Over Hydraulic Brakes

* Deck on Neck (Removable)

* Sliding Winch Track and Winches

* Underbody Tool Box(es)

* Additional Rear Ramps Available

* Third Fold Over Ramp Option (5' DT)

* Mega Ramps (5' DT)

* Center Pop-Up (5' DT)

* Straight-Deck (No DT)

* Hydraulic Dovetail

Lengths Available (Others by special order):

22GN 20' + 5' Dovetail $9989 *This model shown.

22GN 25' + 5' Dovetail $10265

22GN 28' + 5' Dovetail $10985

22GN 35' + 5' Dovetail $11825

22GN 40' Straight Deck $11997

*Above pricing for dovetail models include standard 5' fold over ramps.

Big Tex Trailer World’s network of stores has the largest selection of inventory in the nation with over 10,000 trailers in stock at all times. Should your local store be out of stock of the unit you desire, we can arrange for transfers from other locations or offer alternatives to get you on the road today.
