Logan Stockman Combo 20'
NEW 2012 LOGAN 20' Stockman Combo
STOCKMAN: Standard Features
STRUCTURAL
7' Tall, 7' 3" Wide (7' Wide inside)
5' Taper Gooseneck Nose
Galvanized Structural Tubing In Walls And Floor (No Black Steel)
One-Piece Aluminum Skin Roof With Aluminum Cove And Roof Bows
8 Year Structural Warranty And 2 Year Hitch To Bumper Warranty
2"x2" Cross Members On 16" Centers
WHEELS AND AXLES
Dexter Torsion Axles With Self Adjusting Brakes
Goodyear Radial Tires With Radial Spare Tire
Steel Wheels With Center Cap
EXTERIOR
Aluminum .100 Interlocking Extruded Sides On Lower Panel Of Stall Area And Aluminum .050 Side Sheets On Upper Panel And Front (Attached With 3M VHB Bonding System)
Solid Color Side Sheets
Vortex Rubber Coating Under Gooseneck
Stainless Steel Front Wrap
Extruded Aluminum Ribbed Running Boards And Fenders
Rubber Bumper E-Z Key System - One Key Fits Every Lock
.100 Formed Aluminum Fender
STALL AREA
Corrugated Triple-Wall Construction 48" High With Vortex Rubber Coating
Extruded Aluminum Self-Draining Floor With Vortex Rubber Coating (Whiz Proof) And Rubber Floor Mats
Slatted Air Space (Head And Tail Side)
Rear Gate with slam latch on Cam-Latch
Center Gate With Slam Latch
Escape Door (passenger side)
Interior and Exterior Tie Rings
ELECTRICAL
Dome Lights Without Remote Switch In Stall Area
Sealed Beam Marker And Tail Lights
STOCKMAN COMBO - All the Features of the STOCKMAN and the following:
TACK/DRESSING ROOM
Straight Wall between Tack Area and Stall Area
Single-Wall Construction With Vortex Covered Wall Tubes
Removable Carpet On Floor
Swing-Out Saddle Rack With Gas Assist Shock
4 Tier Blanket Bar
Brush Tray on Door
Twelve Bridle Hooks
Carpet On Top Half Of Angle Wall (GN Includes Carpet On Drop Wall & Deck)
ELECTRICAL
Dome Lights With Remote Switch In Tack Room
STOCKMAN COMBO 20' GN SPECS:
Empty Weight: 5,420 lbs.
Tires: ST235/80/R16
Torsion Axles: 7,000 lbs.
Tongue Weight: 1,465 lbs.
Tire Capacity: E rated-3,400 lbs.
Weights & measurements are approximate.
Financing available on this unit!
